EU3212-MAX Straight Punch 30° Acute – 150mm Working Height | Silver Class

Reference: BPS_150_26_30

Condition: New product

EU3212-MAX — 150mm working height curved-throat acute punch, 26mm body, 30° bending angle. Silver Class. Produces the sharpest air-form bend in a single stroke — preferred for deep-reach enclosure work and stage bending across the UAE and GCC.

More details

22 Item Items

Pre Order

More info

Technical Specifications

Punch Height (H)	150.00 mm
Body Thickness (B)	26.00 mm
Bending Angle	30.00°
Material Grade	42CrMo4
Tip Hardness	55–62 HRC
Body Hardness	45–50 HRC
Tolerance Class	DIN 7168 Fine
Standard Set Length	835 mm
Segment Composition	1×100mm ear + 3×800mm + 2×100mm + 2×200mm + 1×100mm ear
Product Grade	Silver Class
EU Drawing Reference	EU3212

Clamp System Compatibility

AFH / Euro Style — AMADA™, Bystronic™, Durma™, Ermaksan™, and most Euro-clamp CNC press brakes
AMADA™ Direct-Mount — AMADA™ native clamp systems

Parameters Confirmed Upon Order

The following parameters are customer-defined. TFI Co. will confirm these via email upon receipt of order:

Tip Radius (R): Standard options: 0.6 mm / 0.8 mm. Custom radius available on request.
Segment Composition: Standard configuration: 1×100mm ear + 3×800mm + 2×100mm + 2×200mm + 1×100mm ear. Custom segment arrangement available at no extra cost.

TFI Co. provides these technical specifications as a reference only. TFI Co. accepts no liability if a third-party manufacturer applies these specifications and is unable to achieve equivalent product quality. The manufacturing outcomes of any external production facility are entirely beyond TFI Co.’s control and responsibility.

The 150 mm tall version of the EU3212 acute profile with the same curved throat body that avoids interference on consecutive bends. At 30° it produces the sharpest air-form bend achievable in a single stroke, and the extended working height provides clearance for deeper boxes where the return flanges of already-bent sides would obstruct a shorter punch. The go-to tool for deep-reach precision enclosure work, stage bending, and hemming pre-bend operations on taller assemblies.

TFI Co. provides precision press brake tooling for the metalworking industry, manufactured from 42CrMo (Chromium-Molybdenum Steel) — hard, precision-ground, and well-tested for multi-stage bending and box-forming applications. Precision-hardened to 52 HRC, all body thickness dimensions conform to DIN 7168 tolerance standards.

Available for immediate delivery across the UAE (Abu Dhabi, Dubai, Sharjah, Ajman, Ras Al Khaimah), the Kingdom of Saudi Arabia, Oman, and Qatar from TFI Co. logistics centres. All segment sets include one left ear and one right ear piece for press brake punch segments.

All tools come with a maximum tonnage capacity. TFI Co. strongly advises all customers to stay within the rated capacity for staff safety, and to only apply the stated maximum force — not more.

Set Composition

Total: 3200 mm • 9 pieces

1 × 100mm Ear pieces (100mm) 3 × 800mm Main segments (2400mm) 2 × 100mm Main segments (200mm) 2 × 200mm Main segments (400mm) 1 × 100mm Ear pieces (100mm)

Ear pieces	1 × 100 mm (100mm sub-total)
Main segments	3 × 800 mm (2400mm sub-total)
Main segments	2 × 100 mm (200mm sub-total)
Main segments	2 × 200 mm (400mm sub-total)
Ear pieces	1 × 100 mm (100mm sub-total)
Total Set Length	3200 mm

Custom segment arrangements available at no extra cost. Extended or reduced set lengths available on request.
