Straight Bending Punch 90° H150 B26 — EU3211
TFI_BPS_150_26_90_wMK
New product
Standard 90° straight press brake punch (EU3211). H=150mm, B=26mm. 42CrMo4 steel, Gold Class. Set of 5×150mm + 2×42.5mm ear pieces = 835mm total. Compatible with all Euro/AFH and Amada direct-mount clamp systems.
41 Items
Pre-order — ships from Sharjah within 5–7 working days
More info
Technical Specifications
| Punch Height (H) | 150.00 mm |
| Body Thickness (B) | 26.00 mm |
| Bending Angle | 90.00° |
| Material Grade | 42CrMo4 |
| Tip Hardness | 55–62 HRC |
| Body Hardness | 45–50 HRC |
| Tolerance Class | DIN 7168 Fine |
| Standard Set Length | 835 mm |
| Segment Composition | 5×150mm + 2×42.5mm |
| Product Grade | Gold Class |
| EU Drawing Reference | EU3211 |
Clamp System Compatibility
- AFH / Euro Style — AMADA AFH, Bystronic, Durma, Ermaksan, and most Euro-clamp CNC press brakes
- AMADA Direct-Mount — AMADA native clamp systems
Parameters Confirmed Upon Order
The following parameters are customer-defined. TFI Co. will confirm these via email upon receipt of order:
- Tip Radius (R): Standard options: 0.6 mm / 0.8 mm / 1 mm. Custom radius available on request.
- Segment Composition: Standard configuration: 5×150mm + 2×42.5mm. Custom segment arrangement available at no extra cost.
Set Composition
Total: 3145 mm • 9 pieces
3 × 835mm Main segments (2505mm)
4 × 110mm Spacer (440mm)
2 × 100mm Ear pieces (200mm)
| Main segments | 3 × 835 mm (2505mm sub-total) |
| Spacer | 4 × 110 mm (440mm sub-total) |
| Ear pieces | 2 × 100 mm (200mm sub-total) |
| Total Set Length | 3145 mm |
Custom segment arrangements available at no extra cost. Extended or reduced set lengths available on request.
